MOULTON

XTB

Moulton XTB bicycle in steely grey with SRAM Rival 11-speed drivetrain, front angle view

XTB

£4,715.00

The Moulton XTB is the contemporary cross-terrain interpretation of the original AM-ATB, widely recognised as the world’s first production full-suspension mountain bike. Designed for gravel, forest tracks and mixed-surface riding, it builds upon the hairpin spaceframe with reinforced bracing, dual rear fork uprights and uprated suspension. Stronger, lighter and more purpose-specific than its predecessor, the XTB brings Moulton engineering into rougher terrain while retaining separability, load-carrying capability and the unmistakable ride composure that defines every Moulton.

Monosphere

Leading Link

20" Wheel

Separable

CURRENT LEAD TIME

The current production lead time for the XTB is:

2 - 4 months

DELIVERY

We currently ship our bikes to locations in the UK. For international customers, please visit your nearest Moulton stockist or contact us.

Build Spec: Shimano Alfine 11

XTBShimano Alfine 11

£4,715.00

XTB

Key Features

Wheel Size	20" (406mm)
Front Suspension	Leading Link (unicrown)
Rear Suspension	Monosphere
Separability	Separable
Frame Coupling	Centre bolt + alloy locknut
Frame Material	Columbus Spirit and Reynolds 525 CrMo steels (stainless steel dropouts)
Frame Construction	Fillet brazed, hairpin construction. Tubular zig-zags.
Bottle Mounts	4 sets: seat tube, lower rail, 2x head tube
Frame Finish	Powder Coat

Build Specifications

Shimano Alfine 11

SRAM Rival 11

Overview

Ride Category

City & Leisure
Gravel & Off-road

City & Leisure (flat bar)
Gravel & Off-road
Touring & Adventure

Brake Type

Front V-brake + Rear Mech. Disc

Handlebar Type

Flat

Flat or Drop

Gear System

Hub

Derailleur

Drive Train

Front Mech

n/a

Rear Mech

n/a

SRAM Rival 1

Crankset

Shimano Alfine 45t w/chainguard

SRAM Rival 1, 42t

Cassette

20t

Custom 9-36t

Chain

Connex 900 9 speed

Connex 11sX

Bottom Bracket

Shimano Hollowtech II

SRAM GXP

Gear Range (inches)

24-97" (45t)

23-93" (42t)

Brakes

Brakes

Front Shimano V + Rear TRP Spyre disc

Gear/Brake Levers

Shimano Alfine (flat) or Shimano Hollowtech (drop)

SRAM Apex Trigger (flat) or SRAM Rival 1 (drop)

Cockpit

Handlebar

M Special flat bar

M Special flat bar or Deda Speciale classic drop (44 o-o)

Tapes/Grips

Triple-density with bar end hooks

Triple-density with bar end hooks (flat) or Brooks Cambium rubber tape (drop)

Handlebar Stem

AL ahead stem (90, 110 or 135mm)

Headset

Tange Seiki RDC 1" sealed

Seat

Saddle

Selle San Marco Regal Short Dynamic 165

Seatpost

31.6 CNC Aluminium, in-line (lightweight)

Wheels

Tyres

Schwalbe Billy Bonkers 50-406

Rims

Double Wall Black (CNC brake track)

Rear Hub

Moulton custom forged 28h silver

Shimano Alfine 11 speed 32h silver

Front Hub

Moulton custom forged 28h silver

Spokes

Sapim Laser/Force butted (differential)

Mudguards

Available as accessory

Mudguard Clearance

Up to 50mm tyre section

Other

Pedals

MKS Promenade q/r

none supplied

Weight

12 kg / 26.4 lb

11.3 kg / 24.9 lb

XTB

Geometry

Stack	525mm
Reach	377mm
Head Tube Length	254mm
Seat Tube Length	450mm
