MOULTON

FLYTE

FLYTE

£3,985.00

The Moulton Flyte is the long-awaited realisation of Alex Moulton’s Y-frame concept - a fixed-frame, non-separable design that distils the essence of the original F-frame into a modern, lighter and structurally refined form. Re-engineered for contemporary components and built in fillet-brazed NiCrMo steel, the Flyte delivers the stiffness and composure expected of a road-orientated Moulton while remaining leisure focused with a more accessible aesthetic. It is a thoroughbred interpretation of the original Moulton idea, engineered with clarity, not excess.

Monosphere

Leading Link

20" Wheel

Fixed Frame

CURRENT LEAD TIME

The current production lead time for the FLYTE is:

2 - 4 months

DELIVERY

We currently ship our bikes to locations in the UK. For international customers, please visit your nearest Moulton stockist or contact us.

Build Spec: Campagnolo Centaur 2x11

FLYTECampagnolo Centaur 2x11

£3,985.00

FLYTE

Key Features

Wheel Size	20" (406mm)
Front Suspension	Leading Link (crown)
Rear Suspension	Monosphere
Separability	Fixed
Frame Material	Columbus Spirit and Reynolds 525 CrMo steels (stainless steel dropouts)
Frame Construction	Fillet brazed
Bottle Mounts	2 sets: seat tube & head tube
Frame Finish	Stove Enamel

Build Specifications

Campagnolo Centaur 2x11

Shimano Alfine 11

Shimano 105 2x11

Overview

Ride Category

Road & Race
Touring & Adventure

City & Leisure

City & Leisure (flat bar)
Touring & Adventure
Road & Race

Brake Type

Caliper

Front Caliper + Rear Mech. Disc

Caliper

Handlebar Type

Drop

Flat

Flat or Drop

Gear System

Derailleur

Hub

Derailleur

Drive Train

Front Mech

Campagnolo Centaur Black

n/a

Shimano 105

Rear Mech

Campagnolo Centaur Black

n/a

Shimano 105

Crankset

Campagnolo Centaur Black 52/36 or 58/44

Shimano Alfine 45t w/chainguard

Shimano 105 53/39

Cassette

Moulton 10-32

17t

Moulton 10-32

Chain

Connex 11sX

Connex 900 9 speed

Connex 11sX

Bottom Bracket

Campagnolo Ultra-Torque

Shimano Hollowtech II

Gear Range (inches)

21-96" (52/36t) or 26-107" (58/44t)

25-105" (45t)

23-98" (53/39t)

Brakes

Brakes

Tektro R539 DP 57 caliper

Front Tektro R539 DP 57 caliper + Rear TRP Spyre disc

Tektro R539 DP 57 caliper

Gear/Brake Levers

Campagnolo Centaur Black

Tektro FL750 / Shimano Alfine rapidfire

Shimano 105

Cockpit

Handlebar

Deda Speciale classic drop (44 or 42 o-o)

M Special flat bar

M Special flat bar or Deda Speciale classic drop (44 or 42 o-o)

Tapes/Grips

Brooks Cambium Rubber

Brooks Cambium Ergonomic

Brooks Cambium Rubber

Handlebar Stem

AL ahead stem (90, 110 or 135mm)

Headset

Tange Seiki RDC 1 1/8" sealed

Seat

Saddle

Selle San Marco Regal Short Dynamic 140

Selle San Marco Regal Short Dynamic 165

Seatpost

Moulton Titanium, 34.9 dia, layback head

Wheels

Tyres

Schwalbe One (folding) 28-406

Rims

Moulton MT20 Black (CNC brake track)

Rear Hub

Moulton custom forged 28h silver

Shimano Alfine 11 speed 32h silver

Moulton custom forged 28h silver

Front Hub

Moulton custom forged 28h silver

Moulton custom forged 28h silver 70mm

Moulton custom forged 28h silver

Spokes

Sapim Laser/Force butted (differential)

Sapim Laser butted front/PG rear

Sapim Laser/Force butted (differential)

Mudguards

Available as accessory

Mudguard Clearance

Up to 28mm tyre section

Other

Pedals

none supplied

MKS Promenade q/r

none supplied

Weight

10.5 kg / 23 lb

12 kg / 26.4 lb

10.8 kg / 23.7 lb

FLYTE

Geometry

Stack	496mm
Reach	399mm
Head Tube Length	230mm
Seat Tube Length	450mm
